Where to Put the SD Card in the Switch OLED

The Nintendo Switch OLED's microSD card slot is hidden beneath the wide adjustable kickstand on the back of the console. Simply lift the stand to access the slot. One important detail to remember is that the Switch OLED uses microSD cards, not full-size SD cards. The slot on the top edge of the console is reserved exclusively for physical game cartridges and cannot be used for storage expansion.

Many new Switch OLED owners mistakenly assume the game card slot is also the memory card slot, especially when setting up the console for the first time. In reality, the two are located in completely different places. In this guide, we'll show you exactly where to find the microSD card slot, how to insert a card correctly, and a few common mistakes to avoid during installation.

Where Is the microSD Card Slot?

To locate the card slot, turn the device over and open the large, adjustable stand on the back. The card slot is located beneath the stand and can be accessed without removing any screws, covers, or panels. Follow these steps:

• Hold the device with the screen facing away from you.

• Locate the large, adjustable stand on the back.

• Lift the stand.

• Look for the small microSD card slot beneath the stand.

The slot on the top edge is a different slot. That slot is for inserting Switch game cartridges, not memory cards. If you previously looked only at the top edge and didn’t find the slot, you likely mistook its location. Please note that the microSD card slot is hidden under the back cover, and you must open the cover to see it.

How Do You Insert a microSD Card?

Be sure to insert the microSD card only after the console has been completely turned off and the rear cover has been opened. If you attempt to insert the card while the console is still on, the system may not recognize it.

Turn the Console Off

Be sure to completely shut down the OLED console before inserting or removing a memory card. “Sleep mode” is not the same as a complete shutdown. Therefore, please use the power button to shut down the system rather than simply putting it into sleep mode.

Open the Adjustable Stand

Lift the wide bracket on the back of the device upward to reveal the slot underneath. This bracket can be opened without removing any screws or covers. Therefore, do not force it beyond its normal range of motion.

The design of the protective case is also crucial here. Whether the slot is easy to use depends on how the case is cut out around the rear bracket. This is why it’s worth investing in a well-designed protective case. Mumba Nintendo Switch OLED case collection leaves the stand and card slot clear.

Insert the Card the Right Way

Hold the card with its label facing away from the console, then push it in gently until it clicks and seats securely. Do not force it if the resistance feels wrong. Pull it out, check the orientation, and try again. A card can look inserted while it is not fully seated, and in that state the console may not recognize it after startup. Close the stand, turn the console back on, and confirm the storage shows up.

Which microSD Cards Can You Use?

The Switch OLED model supports microSD, microSDHC, and microSDXC cards with a maximum capacity of 2TB. Nintendo recommends using UHS-I cards with transfer speeds between 60 and 95 MB/s. This is because faster memory cards can reduce the loading time for downloadable games. The table below summarizes information about the various formats.

Regarding microSDXC memory cards, there is one point worth emphasizing again: the console requires a system update before it can read this format of memory card for the first time. Therefore, before you plan to use a high-capacity memory card, be sure to connect to the internet and complete the update. The brand of the memory card is not the only factor determining whether the console can read it. The physical specifications and the quality of contact once the card is inserted are equally critical.

Using a compatible memory card can increase the storage space available for downloadable games, screenshots, and recorded videos. However, please note that game save data is stored in the console’s system memory, not on the memory card. Therefore, even if you replace your microSD card with one of greater capacity, you will not free up the space occupied by your save data. If your actual issue is insufficient save space, replacing your memory card with one of greater capacity will not resolve the problem.

Learn More: What Kind of SD Card for Switch 2?

Why Is the Switch OLED Not Reading the Card?

Some players may encounter an issue where the console fails to recognize the memory card. You can check the following in this order:

• Is the memory card inserted properly?

• Is it formatted correctly?

• What is the condition of the memory card?

• What is the system software version?

Generally speaking, most issues stem from the first two problems.

Check the Seating First

First, turn off the power to the unit, remove the memory card, check the insertion orientation, and then reinsert it securely. Restart the unit and check whether the storage device is recognized. If a memory card is already inserted but the unit indicates that the slot is empty, this is usually because the memory card is not fully inserted.

A memory card that is not fully inserted may appear to be installed correctly when viewed from the outside. Therefore, be sure to perform this check before attempting any other troubleshooting steps.

Verify the Format and Condition

First, make sure the memory card is a supported microSD, microSDHC, or microSDXC type. If the physical specifications do not match, do not force it into the slot.

Next, check the memory card for dirt, damage, or contaminants. Also, check the slot for any visible foreign objects. Never insert metal objects, liquids, or homemade cleaning tools into the slot, as this may damage the card reader.

Check the System Software

If a memory card that has been confirmed to be in good condition still cannot be read, please check the system software version and Nintendo’s current compatibility guidelines. Pay particular attention to any updates required for microSDXC format support. If multiple memory cards known to be compatible still do not work, please contact Nintendo Customer Support for assistance.

Conclusion

You can install a microSD card by following the steps outlined above, but be sure to power off the console first. If you're using a microSDXC card, the Nintendo Switch OLED may require a system update before the card can be recognized. Also remember that, regardless of the card's capacity, save data is stored on the console's internal memory, not on the microSD card.

If you're setting up a new console, check out our guide on What Is the Nintendo Switch OLED? Once your memory card is installed, it's also worth choosing a case that doesn't interfere with access to the rear stand or microSD card slot. The Mumba OLED-specific cases feature precise cutouts for both, making storage upgrades and tabletop gaming easy. Plus, U.S. orders over $49 qualify for free shipping, and every case is backed by a one-year warranty.

Frequently Asked Questions

What is the maximum microSD card size for the Switch OLED?

The OLED supports microSD cards up to 2 TB. For the best performance, Nintendo recommends UHS-I cards with a transfer speed of 60 to 95 MB per second. A microSDXC card, which covers anything above 32 GB, needs a system update before first use.

Do I need to format the microSD card before using it?

The console prompts you if a card needs formatting when you first insert it. Formatting on the Switch erases the card, so back up anything on it first. A brand new card usually works right away once the console recognizes it.

Can I move my existing games to a new microSD card?

Not directly on the console. The Switch has no built-in card-to-card transfer, so you generally redownload digital software onto the new card from your account. Save data stays in System Memory either way, so it is not tied to the card you swap out.

Can I use a regular SD card in a Switch OLED?

No. Standard-sized SD cards do not fit into the card slot of the OLED model. This console only supports microSD, microSDHC, and microSDXC cards. Therefore, please be sure to check the card specifications before purchasing.

Do I have to turn off the Switch OLED before removing a microSD card?

Yes. Be sure to completely shut down the device before inserting or removing a memory card. Sleep mode does not count as a complete shutdown, so please use the power button to completely shut down the system first.
